Series 1200H Hygienic Variable Area Flowmeter

GENERAL INFORMATION

The MPB Series 1200H Hygienic Flowmeter is manufactured from stainless steel throughout, with the exception of fully stress relieved flow tube.  The flow tube is calibrated with a permanently fired black scale and can be supplied with a white backing if required.

The unit is easily removed from the line with Triclamp stainless steel connections where the flowmeter can easily be cleaned.

For protection, the 1200H Hygienic Flowmeters are fitted with a tubular, virtually unbreakable, polycarbonate safety covers.

A wide range of flow tubes are available and MPB can calibrate and scale tubes to customers’ requirements.

The MPB Long Series 1200HL Hygienic Flowmeter has a flow tube length of 295mm, is for use where high resolution scale accuracy is required.

The 1200H Hygienic Flowmeter has a flow tube length of 138mm.



Download Technical Bulletin which shows standard flow rates: Technical Bulletin



For further information please complete the form below, or contact us direct by telephone or e-mail.

Tel: +44 (0)1622 872401
Email: sales@mpbflowmeters.com





Description

MPB SERIES 1200H FEATURES

  • TWO STANDARD LENGTHS AVAILABLE
  • RANGE OF STANDARD FLOW RATES
  • STANDARD OR CUSTOMISED FLOW SCALES
  • TUBULAR POLYCARBONATE SAFETY COVER
  • STAINLESS STEEL TRICLAMP CONNECTIONS
  • DIRECT READING OF INSTANTANEOUS FLOW RATE
  • FRICTIONLESS, HENCE LOW HEAD LOSS
  • EASY TO READ SCALE
  • EASY IN-SITU FLOWMETER REMOVAL AND RE-INSTALLATION
  • MINIMAL MAINTENANCE AND LONG SERVICE LIFE

SPECIFICATION

End Connections:  Stainless steel 25mm Triclamp Hygienic fittings

Cover: Polycarbonate

Seals: Nitrile, Viton, EPDM, etc

Metering Tube: Borosilicate glass (138mm and 295mm long)

Scale: Permanently fired black ceramic

Plumb Bob Floats: Stainless steel

Ball Floats: Glass, Stainless steel, Ceramic, Ruby, Tungsten

Weight: 570/670 grams (standard)

Maximum Working Pressure: Liquid: up to 20 bar g (non-shock)

Maximum Working Temperature: 60°C Nitrile, 1000C Viton

Accuracy: ± 5% FSD predicted, ± 2% FSD series – calibrated
